Double Oil Double Gun Flexible Fuel Dispensers

Product Description

Meet the next generation in fuel blending

Your customers are demanding more and more alternative fuel options. The Encore NF Series helps broaden your fuel offering while keeping the fueling experience simple and safe. With the industry's broadest set of flexible fuel options, the NF Series offers up to six product selections from one fueling position. It's a smart investment that lets you maximize branding and sales opportunities, while keeping the numbers of tanks needed to a minimum.


Product Parameters



Accuracy
±0.30%
Repeating Accuracy
≤0.10%
Flow range
(5~55) L/min
Maximum head
5m
Inlet Vacuum
≥54kPa
Outlet Vacuum
≤0.3MPa
Work pressure
<300 kPa
Noise
≤70dB(A class)
Unit price range
0~9999, 0~999999 (changeable)
Single range
1~9999.99,1~999999.99 (changeable)
Accumulative range
0~9999999999.99
Input hose diameter
38mm
Oil hose diameter
19mm
Explosin-Proof motor power
750W(or 1000W)
Ambient Temperature
-35ºC~+55ºC
Humidity
≤95%
Atmospheric Pressure
86kPa~106kPa
Power(optional)
AC110V±20%, AC220V±20% , AC380V±20% (50Hz)

Composition


Features & Benefits

1. Meet the refueling function and adopt a 32-inch human-computer intelligent interactive touch screen, the oil product and non-oil marketing interface can be switched at any time, increasing human-computer interaction and promoting sales;
2. The large LED screen of the top box can be linked with the 32-inch large screen of the fuselage to display the oil product label, oil price, customer refueling information, advertising promotion information, weather forecast, etc. in real time. In order to realize the reconstruction of the operation area and the publicity area, the license plate payment and ETC non-inductive payment functions are linked, and the license plate number and other information can also be displayed;
3. The side arm of the fuel dispenser also has a built-in silent guide hose stretcher, which can stretch and stop the hose as it is pulled, saving time and effort, and avoiding the hose being mopped and rolled. The inner side of the side arm hose box is designed with a roller mechanism to reduce the friction of the hose and improve the service life of the hose. The overall design of the hose stretching mechanism reduces the labor intensity of employees, which is safe and convenient;
